TECHNICAL DATA
Electrical Information
2-9317-372-00-0 Bravo™ 8105 Programming and Operations Guide 2-23
Section B: Machine Components
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction Refer to the following information for component specifications.
Forced Convection
Heating Module Table
Convection Blower
Specifications Table
Note: Differences in cfm rating between 50 Hz and 60 Hz show less than +
2 C
(+
4 F) thermal profile variance between identical process parameters on typical
assemblies.
Heating Chamber Length 2667 mm (105 in.)
Air Diffuser Panel
Dimensions
Length: 254 mm (10 in.)
Width: 508 mm (20 in.)
Heater Power Rating 4000 W per panel in zones 2
through 6
5000 W per panel in zones 1, 7
and 8.
1000 W per Rail Heater
Maximum Heating
Capacity
245,893 BTU/hr) 72kW
Heater Temperature Range Ambient to 300 C (572 F)
Typical Time to Ready
State
+
15 minutes
Blower Rating at 0 Static
Pressure
595 m3/hr (300 cfm)
TOTAL FORCED
CONVECTION
60 Hz 50 Hz
Top (8 Blowers) 4080 m3/
Hr
(2400
cfm)
3876 m3/
Hr
(2280
cfm)
Bottom (8 Blowers) 4080 m3/
Hr
(2400
cfm)
3876 m3/
Hr
(2280
cfm)
TOTAL (16 Blowers) 8160 m3/
Hr
(4800
cfm)
7752 m3/
Hr
(4560
cfm)
