TECHNICAL DATA
Overview
2-20 Bravo™ 8105 Programming and Operations Guide Rev. 2
2
Section A: Facility Requirements and Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction These general facility requirements cover several available options. During
preliminary preparation and system set up refer only to those items relating to the
system ordered or purchased.
Exhaust Requirements The following exhaust specifications assist in determining an exhaust blower
capable of exhausting the system. Measure all exhaust measurements at the
machine exhaust port. Proper exhaust ensures correct machine operation and
safety.
Contact your local HVAC specialist for blower requirements and ventilation hook-
up.
Tables The following table identifies the facility requirements for Bravo™ 8105 operation:
Exhaust Requirements
Recommended venting material 152.4 mm (6.0 in.) diameter
Standard HVAC exhaust flex hose
Standard Air Machine Requirements
Load End
Unload End
Middle (hood exhaust)
Total Exhaust
170 m
3
/hr (100 cfm)
425 m
3
/hr (250 cfm)
255 m
3
/hr (150 cfm)
1104 m
3
/hr (650 cfm)
Nitrogen (Inert) Machine Requirements
Load End
Unload End
Middle (hood exhaust)
Total Exhaust
255 m
3
/hr (150 cfm)
255 m
3
/hr (150 cfm)
255 m
3
/hr (150 cfm)
1019 m
3
/hr (600 cfm)
Exhaust Notes:
Take all exhaust measurements at the machine exhaust port.
