CHAPTER 2: Instructor / Operator’s Station (IOS)
Profi le View Examples:
The following example profi les dem on strate sev er al of the
different view options de scribed in the previous section.
The profi le was created fl ying the ILS RWY 7 approach into
Orlando Executive (ORL) airport. For illustration purposes,
the glideslope was tracked to the non-pre ci sion Min i mum
Descent Altitude (MDA) and NOT to Decision Height (DH).
A level-off at MDA and subsequent missed ap proach was
start ed short ly there af ter.
Level-off at
MDA
Aircraft at
Glideslope
Intercept
Glideslope
Missed
Approach
Actual Aircraft Track
Profi le view of ILS RWY 7 approach into Orlando Executive airport.
