258 Troubleshooting
2. Tilt the green levers toward you as shown below.
c
Caution:
❏ Do not move the black lever.
❏ Do not touch the transfer roller (black rubber roller) of
the transfer unit or the transfer roller of the intermediate
transfer unit. Touching them may deteriorate print
quality, or damage the transfer roller and require
replacement.
a. Transfer roller of the transfer unit
b. Transfer roller of the intermediate transfer unit
a
b
To Next Page
