7-2 Application Development for Image Scanner Rev. E
5. Endorsement printing has been done.
6. Print position for the surface printing is completed.
7. Surface printing has been done.
The area for the reverse printing is limited; therefore when
setting the print area for single-pass processing, be sure to
note that the printing on the surface cannot be done
within 40 mm (typical) from the bottom of the paper.
9. Image scanning has been done.
The direction
the paper has
been fed
(reverse).
Endorsement
head
Print head
The direction
the paper has
been fed
(reverse).
The direction the paper
has been fed (forward).
Print head
40 mm or more
The direction the
paper has been fed
(forward).
Image scanner
