3-18 Setup Rev. E
3.4 Customizing
This printer is able to be customized for the items below:
❏ Roll paper near end detector
❏ DIP switch (communication condition, print density, etc...)
❏ Memory switch (some notices enable/disable, roll paper type, error signal output, paper jam
detection for slip, and unit cover open while printing)
The current settings can be confirmed by a self-test.
3.4.1 How to Confirm Current Settings
You can use a self-test to confirm the current settings. “Self Tests” on page 3-24
3.4.2 Adjusting the Roll Paper Near End Detector
The paper near end detector detects when paper is almost gone by measuring the diameter of
the paper roll. The detector has two settings.
Note:
Because of variations in paper roll cores, it is not possible for the detector to measure exactly the length of
paper left on the roll when the detector is triggered.
If you want more paper left when the detector is triggered, change the setting, as described
below.
1. Open the printer cover, and remove the paper roll.
2. Loosen the adjusting screw with a coin, and carefully move the detecting lever up.
3. Tighten the adjusting screw, and check to be sure that the detecting lever moves freely.
4. Replace the paper roll.
Adjusting
screw
Detecting
lever
