3-22 Setup Rev. E
NOTE:
When pin 6 of the interface connector is used for the reset signal, the printer is reset at MARK on the RS-232 level.
Changes in DIP switch settings (excluding switch 2-8, interface reset signal) are recognized only when the printer
power is turned on or when the printer is reset by using the interface. If the DIP switch setting is changed after the
printer power is turned on, the change does not take effect until the printer is turned on again or is reset.
If you turn on DIP switch 2-8 while the printer is turned on, the printer may be reset, depending on the signal state.
DIP switches should not be changed while the printer power is on.
If the print density is set to level 3 or 4, print speed is reduced as follows:
Maximum 180mm/s at 24V, 25°C in level 3
Maximum 170mm/s at 24V, 25°C in level 4
For a tip about print density, see “When Using Original Paper” (page 3-23).
3.4.3.4 USB interface model
Print density
NOTE:
If the print density is set to level 3 or 4, print speed is reduced as follows:
Maximum 180mm/s at 24V, 25°C in level 3
Maximum 170mm/s at 24V, 25°C in level 4
For a tip about print density, see “When Using Original Paper” (page 3-23).
DIP Switch 1
SW Function ON OFF
1-1 Auto line feed Always enabled Always disabled
1-2 Receive buffer capacity 45 bytes 4KB
1-3~
1-8
Reserved Fixed to OFF
DIP Switch 2
SW Function ON OFF
2-1 Handshaking
(BUSY condition)
Receive buffer full Offline or receive
buffer full
2-2 Customer display
connection
Connected Not connected
2-3 Print density (See the table below.)
2-4
2-5~
2-6
Internal use (Do not
change setting.)
Fixed to OFF
2-7 Reserved (for serial
interface)
Fixed to OFF
2-8 Reserved Differs depending on printer specifications.
Print Density SW 2-3 SW 2-4
1 (Light) ON ON
2↑ OFF OFF
3↓ ON OFF
4 (Dark) OFF ON
