1-26 General Information Rev. E
❏ The values in the table above are measured in the following conditions, but are just for your
reference.
❏ The Epson original power supply PS-180 can print within the print duty above.
❏ Contact Epson if you need more detailed information.
Environmental temperature: 5° C {41° F}
Supply voltage: 24 V
Print pattern: See figures below
Measurement terminal: At the connector of the printer's power supply
Print density: Print density level 2
The print density levels 3 and 4 are higher by +15% and +30%
respectively than the value of the level 2 in the table above.
72 mm 72 mm
300 mm
7890
abcd
42 columns
(Font A)
Alphanumeric rolling pattern with
full column printing
1 dot for square
300 mm
Ԙ
ԙԚ
Figure ’A’ Figure ’B’ Figure ’C’
