8. Verifying Robot System Operation
When maintenance has been performed for either the Manipulator or the Controller,
including replacing any parts in those units, items must be checked according to the
procedures in this section to ensure proper operation.
(1) Connect all the necessary cables for the system.
WARNING
■
When verifying the robot system operation, prepare for failures with initial
settings or wiring. If the M
anipulator operates abnormally because of incorrect
initial settings or wiring, press the Emergency Stop switch immediately to stop
the Manipulator.
Verify the robot system operation in the restricted mode (low speeds and low
power) status. Verifying the robot system operation at high speeds may
damage the robot system and/or cause serious safety problems as the
Manipulator cannot stop operating immed
iately in case of abnormal operation of
CAUTION
■
The serial number of the Manipulator that should be connected is indicated on
the
Connection Check Label on the Controller. Connect the Controller and the
Impro
per connection between the Controller and the
Manipulator may cause not only improper function of the robot system but also
serious safety problems.
(2) Check the LED status during the time from the Controller is turned ON until the
Controller boots up by referring to the list below.
LED All blink
LED for current operation mode
(TEST, TEACH, AUTO, PROGRAM)
7 segment All lights out
READY (Normal)
Emergency Stop
Safeguard
For details of the display, refer to Setup & Operation
Seven-segment LED.
For error numbers, refer to Maintenance 9.1 Error Code Table.
(3) Execute MOTOR ON and check the following:
- No error is displayed.
- There is servo excitation and the Manipulator operates normally.
(4) Execute various motion commands (such as JUMP, etc.). The Manipulator must
operate accordingly and normally without vibration or unusual sounds.
