Setup & Operation 14. Option Slots

90 RC700 / RC700-A Rev.23

14.3 Fieldbus I/O Board

The Fieldbus I/O board has the following six types.

- DeviceNet

- PROFIBUS-DP

- PROFINET

- CC-LINK

- EtherNet/IP

- EtherCAT

For the details, refer to the Robot Controller RC700/RC90 Controller Option Fieldbus I/O

manual.
