Epson RC700 Series User Manual

Safety 4. Operation Mode (TEACH/AUTO/TEST)
RC700 / RC700-A Rev.23 37
4.3 Program Mode (AUTO)
4.3.1 What is Program Mode (AUTO)?
Program mode is for programming, debug, adjustment, and maintenance of the Robot
system.
Follow the procedures below to switch to the Program mode.
4.3.2 Setup from EPSON RC+
Switch the mode to Program mode from the EPSON RC+.
(1) Select EPSON RC+ menu-[Setup]-[System Configuration] to display the [System
Configuration] dialog.
(2)
(5)
(3)
(4)
(2) Select [Startup]-[Start mode].
(3) Select <Program> button.
(4) Click the <Apply> button.
(5) Click the <Close> button.

Epson RC700 Series Specifications

General

Model	RC700 series
Category	Controller
Programming Language	SPEL+
Safety Standard	ISO 10218-1
Type	Robot Controller
Communication Interface	Ethernet, RS-232, USB
Operating Temperature	0°C to 45°C (32°F to 113°F)
Humidity	20% to 80% (non-condensing)
Number of controllable robots	4
