Setup & Operation 11. I/O Connector
RC700 / RC700-A Rev.23 65
Typical Output Circuit Application 2
10 Output No.0
I/O-1
(Same)
Omit
+DC
29 Output No.8
30 Output No.9
11 Output No.1
12 Output No.2
13 Output No.3
14 Output No.4
15 Output No.5
27 Output No.6
28 Output
No.7
17 Output No.0 to 7 common (+DC)
Load
L
GND
L
33 Output No.8 to 15 common (+DC)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
(Same)
