Embedded AIC (Audio
Input Correction)
Channel 1 - 8 - Configuration for user correction of the audio input for Ch1 – Ch8 including
Gain, inversion and Channel delay for embedded audio.
Channel 9 - 16 - Configuration for user correction of the audio input for Ch9 – Ch16 including
Gain, inversion and Channel delay for embedded audio.
AES AIC (Audio Input
Correction)
Channel 1 - 8 - Configuration for user correction of the audio input for Ch1 – Ch8 including
Gain, inversion and Channel delay for AES Audio.
Channel 9 - 16 - Configuration for user correction of the audio input for Ch9 – Ch16 including
Gain, inversion and Channel delay for AES Audio.
Embedded Audio Mixer
Channels 1 - 4 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH1, CH2, CH3, CH4.
Channels 5 - 8 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH5, CH6, CH7, CH8.
Channels 9 - 12 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH9, CH10, CH11, CH12.
Channels 13 - 16 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH13, CH14, CH15, CH16.
AES Audio Mixer
Channels 1 - 4 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH1, CH2, CH3, CH4.
Channels 5 - 8 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH5, CH6, CH7, CH8.
Channels 9 - 12 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH9, CH10, CH11, CH12.
Channels 13 - 16 - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels CH13, CH14, CH15, CH16.
Down Mix
Configuration for defining the source of audio channels for the 5.1 down-mix process and further
defining the down mix type and level parameters.
Downmix Mixer
Channels L, R, C - Configuration for channel swapping, audio gain, audio inversion and mono
mixing for outbound audio channels L, R, C.
Channels LFE, Ls, Rs - Configuration for channel swapping, audio gain, audio inversion and
mono mixing for outbound audio channels LFE, Ls, Rs.
UpMix Control (+UMX2)
Configures the source audio channel for stereo to 5.1 up-mixing and further defining key up-mix
algorithm parameters. Auto Up-mix will automatically detect whether a stereo or 5.1 audio is
applied at the input
UpMix Mixer (+UMX2)
Channels L, R, C, LFE - Configuration for channel swapping, audio gain, audio inversion and
mono mixing for inbound audio channels L, R, C, LFE on the Up-mix Block.
Channels Ls, Rs, Pass L, Pass R - Configuration for channel swapping, audio gain, audio
inversion and mono mixing for inbound audio channels Ls, Rs, Pass L, Pass R on the Up-mix
Block.
