Extron electronics SMP 300 Series User Manual

SMP 300 Series • Remote Communication and Control 112
X53*
=
Metadata parameter
0 = Contributor
1 = Coverage
2 = Presenter
3 = Date (view only)
4 = Description
5 = Format
6 = Identifier (view only)
7 = Language
8 = Publisher
9 = Relation
10 = Rights
11 = Source
12 = Subject
13 = Title
14 = Type
15 = SystemName (view only)
16 = Course
X53(
=
Metadata value — 127 character maximum
X54)
=
Recording status
0 = Stop
1 = Start
2 = Pause
X54!
=
Recorder time in minutes — 1 to 60
X54@
=
Recording destination
auto
internal
usbfront
usbrear
usbrcp
N/A
X54#
=
File size (in megaBytes)
X54$
=
0 = Recording disabled
1 = Single recording enabled
2 = Dual recording enabled
X54%
=
Thumbnail size
0 = Normal (default)
1 = Follows archive resolution
X54^
=
Recorder status
stopped
recording
paused
X55!
=
Video Output Frame Rate
1 = 30 Hz 5 = 12.5 Hz
2 = 25 Hz 6 = 12 Hz
3 = 24 Hz 7 = 10 Hz
4 = 15 Hz 8 = 5 Hz
X56)
=
Destination
0 = Auto
1 = Internal
2 = USBFront
3 = USBRear
4 = USBRCP
11 = Internal + Auto
12 = Internal + USBFront
13 = Internal + USBRear
14 = Internal + USBRCP
X56#
=
Encoder Presets — 1 to 32
X56$
=
Audio delay — 0 to 999 ms
X56%
=
Test patterns (0 to 8)
0 = Off (default)
1 = Color bars
2 = Aspect ratio 1.33
3 = Aspect ratio 1.78
4 = Aspect ratio 1.85
5 = Crop
6 = Pulse
7 = Timestamp (Composite mode only)
8 = Universal OSD (Composite mode only)
X56^
=
RTMP URL (string)
X56&
=
Audio output
1 = Ch A
2 = Ch B
3 = Ch A + Ch B
4 = Ch A + Ch B (Analog dual mono enabled only)
5 = Ch B (Analog dual mono enabled only)
X58!
=
Front panel audio level indication
-1500 to 
Full bars = 0
No bars = <-600
Format: left*right
Example: -58*-63
X58@
=
Recording mode
0 = Channel A disabled
1 = Single Recording in Composite mode
2 = Internal + Secondary Recording in Composite
mode
X59!
=
USB Storage
0 = All USB storage
2 = USBFront
3 = USBRear
4 = USBRCP
X59@
=
Valid DB_ID number (integer)
X59#
=
Delay duration in seconds — 5 to 60.
X59%
=
Virtual inputs — 1 = input 1, 2 = input 2
X59^
=
RTSP stream URL
X60#
=
Pixel phase adjustment — 0 to 63 (default = 32)
X60$
=
Horizontal and vertical start — 0 to 255
(default = 128)
X60%
=
Total pixels — Up to + 512 of the default value for
the detected rate
X60^
=
Active lines — Up to + 256 of the default value for
the detected resolution (range varies based on input
resolution)
X60&
=
Active pixels — Up to + 512 of the default value for
the detected resolution (range varies based on input
resolution)
X60*
=
Picture adjust — 0 to 127 (default = 64)
X60(
=
Horizontal centering — Varies based on archive
resolution
X61!
=
Vertical centering — Varies based on archive
resolution
X61@
=
Horizontal size — 120 to 4096
X61#
=
Vertical size — 64 to 4096
