Extron electronics SMP 300 Series User Manual

SMP 300 Series • Remote Communication and Control 125
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Presets continued
Recall Layout Preset (for confidence in Dual Channel mode only)
Recall layout preset
9 * 3*
X53)
. 9Rpr3 *
X53)]
Recall layout preset to
X53)
to
confidence encoder in dual
channel mode.
KEY:
X53)
= User/Encoder/Layout Preset Number 1 to 32
X53!
= Preset Name Up to 16 characters
Input Presets
Recall preset
2*
X50!
*
X53@
. 2Rpr
X50!
*
X53@]
Save preset
2*
X50!
*
X53@
, 2Spr
X50!
*
X53@]
Set preset name E
2*
X53@
,
X53!
PNAM
}
Pnam2*
X53@
,
X53!]
View preset name E
2*
X53@
PNAM
} X53!]
Delete input preset E
X2*
X53@
PRST
}
PrstX2*
X53@]
Query input presets
51#
Verbose mode 2/3
X(
1
X(
2
X(
3
...
X(
128
]
PreI
X(
1
X(
2
X(
3
...
X(
128
]
KEY:
X(
= On/off 0 = Disabled/unassigned/off/unmuted (default), 1 = Enabled/assigned/on/muted
X50!
= Input number 1 to 5
X53!
= Preset Name Up to 16 characters
X53@
= Input preset number 1 to 128
Layout Presets (for composite mode only)
Save layout preset
7 *
X53)
, 7Spr
X53)]
Save layout preset to
X53)
.
Recall layout preset
7*
X53)
. 7Rpr
X53)]
Recall layout preset
X53)
including input selections.
Recall layout preset
8*
X53)
. 8Rpr
X53)]
Recall layout preset
X53)
without input selections.
Set preset name E
7*
X53)
,
X53!
PNAM
}
Pnam7*
X53)
,
X53!]
Set
X53)
to
X53!
.
Query preset name E
7*
X53)
PNAM
} X53!]
Reset layout preset to
defaults
E
X7 *
X53)
PRST
}
PrstX7*
X53)]
Reset
X53)
to defaults
Encoder Presets
Recall preset
4*
X50)
*
X56#
. 4Rpr
X50)
*
X56#]
Recalls Encoder preset
X56# for
X50)
Save preset
4*
X50)
*
X56#
, 4Spr
X50)
*
X56#]
Saves Encoder preset
X56# for
selected channel
Set preset name
E
4*
X56#
,
X51$
PNAM
}
Pnam4*
X56#
,
X51$]
Set encoder preset number
X56#
to name
X51$
.
View encoder preset
name
E
4*
X56#
PNAM
} X51$]
View the name of Encoder
preset
X56#
.
Reset encoder preset to
default
E
X4*
X56#
PRST
}
PrstX4*
X56#]
Clears Encoder preset
X56#,
and sets Encoder preset name
to [unassigned].
KEY:
X50)
= Streaming encoder 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel only)
3 = Confidence
X51$
= Encoder/Streaming preset name Up to 16 characters
X56#
= Encoder presets 1 to 32
