SMP 300 Series • Remote Communication and Control 130
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Picture Adjustments continued
Vertical Centering (for Composite mode only)
Specify a value E
1*
X50@
*
X61!
VCTR
}
Vctr
X50@
*
X61! ]
Set vertical centering
X61!
.
Increment value E
1*
X50@
+ VCTR
}
Vctr
X50@
*
X61! ] Shift window down.
Decrement value E
1*
X50@

}
Vctr
X50@
*
X61! ] Shift window up.
View E
1*
X50@
VCTR
} X61! ] View current setting.
KEY:
X50@
= Output channel 01 = A, 02 = B
X61!
= Vertical centering The value corresponds to the vertical position of the top edge of the window. The range varies, so
the window never goes completely off‑screen (5‑digit response).
Vertical Size (for Composite mode only)
Specify a value E
1*
X50@
*
X61#
VSIZ
}
Vsiz
X50@
*
X61# ]
Set vertical size (height) to
X61#
.
Increment value E
1*
X50@
+ VSIZ
}
Vsiz
X50@
*
X61#] Increase height of the window.
Decrement value E
1*
X50@

}
Vsiz
X50@
*
X61# ] Decrease height of the window.
View E
1*
X50@
VSIZ
} X61# ] View current setting.
NOTE: Vertical centering and vertical size values are adjusted in multiples of 2. If a value is entered that is not a multiple of 2, the closest acceptable
value is applied and returned.
KEY:
X50@
= Output channel 01 = A, 02 = B
X61#
= Vertical size 00064 to 04096 (5‑digit response).
Encoder Settings (Archive Encode and Recording)
Stream Enable/Disable
Stream enable E X50)
*
X(
STRC
}
Strc
X50)
*
X(] Enable or disable each stream.
View stream status
E X50)
STRC
} X(]
KEY:
X(
= Enable/disable 0 = Disabled (default), 1 = Enabled
X50)
= Stream selection 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel mode only),
3 = Confidence
RTMP (primary) Destination URL/Stream Key
Set RTMP URL E
U1*
X50)
*
X56^
RTMP
}
RtmpU1*
X50)
*
X56^] Enter primary publish URL of
X50)
.
View RTMP URL E
U1*
X50)
RTMP
} X56^] View primary publish URL of
X50)
.
RTMP (backup) Destination URL/Stream Key
Set RTMP URL E
U2*
X50)
*
X56^
RTMP
}
RtmpU2*
X50)
*
X56^] Enter backup publish URL of
X50)
.
View RTMP URL E
U2*
X50)
RTMP
} X56^] View backup publish URL of
X50)
.
KEY:
X50)
= Stream selection 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel mode only),
3 = Confidence
X56^
= RTMP URL (string)
RTMP Stream Enable/Disable
Enable RTMP push
stream
E
E
X50)
*
X(
RTMP
}
RtmpE
X50)
*
X(] Enable or disable RTMP push
stream
X50)
.
View RTMP push
stream
E
E
X50)
RTMP
} X(] View status of RTMP push
stream
X50)
.
KEY:
X(
= Enable/disable 0 = Disabled (default), 1 = Enabled
X50)
= Stream selection 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel mode only),
3 = Confidence
