SMP 300 Series • Remote Communication and Control 129
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Picture Adjustments
Color (NTSC and PAL inputs only)
Specify a value E X50@
*
X60*
COLR
}
Colr
X50@
*
X60*]
Sets color level to
X60*
.
Increment value E X50@
+ COLR
}
Colr
X50@
*
X60* ] Increments color level.
Decrement value E X50@
  OLR
}
Colr
X50@
*
X60* ] Decrements color level.
View E X50@
COLR
} X60* ] View current setting.
Tint (NTSC input only)
Specify a value E X50@
*
X60*
TINT
}
Tint
X50@
*
X60* ]
Sets tint level to
X60*
.
Increment value E X50@
+ TINT
}
Tint
X50@
*
X60* ] Increments tint level.
Decrement value E X50@

}
Tint
X50@
*
X60* ] Decrements tint level.
View E X50@
TINT
} X60* ] View current setting.
KEY:
X50@
= Output channel 01 = A, 02 = B
X60*
= Picture adjust 000 to 127, default: 064 (3‑digit response)
Contrast
Specify a value E X50@
*
X60*
CONT
}
Cont
X50@
*
X60* ]
Sets contrast level to
X60*
.
Increment value E X50@
+ CONT
}
Cont
X50@
*
X60* ] Increments contrast level.
Decrement value
E X50@
  ONT
}
Cont
X50@
*
X60* ]
Decrements contrast level.
View E X50@
CONT
} X60* ] View current setting.
Brightness
Specify a value E X50@
*
X60*
BRIT
}
Brit
X50@
*
X60* ]
Sets brightness level
X60*
.
Increment value E X50@
+ BRIT
}
Brit
X50@
*
X60* ] Increments brightness level.
Decrement value E X50@

}
Brit
X50@
*
X60*] Decrements brightness level.
View
E X50@
BRIT
} X60* ]
View current setting.
KEY:
X50@
= Output channel 01 = A, 02 = B
X60*
= Picture adjust 000 to 127, default: 064 (3‑digit response)
Horizontal Centering (for Composite mode only)
Specify a value E
1*
X50@
*
X60(
HCTR
}
Hctr
X50@
*
X60( ]
Set horizontal centering to
X60(
.
Increment value E
1*
X50@
+ HCTR
}
Hctr
X50@
*
X60( ] Shift window right.
Decrement value
E
1*
X50@

}
Hctr
X50@
*
X60( ]
Shift window left.
View
E
1*
X50@
HCTR
} X60( ]
View current setting.
KEY:
X50@
= Output channel 01 = A, 02 = B
X60(
= Horizontal centering The value corresponds to the horizontal position of the left edge of the window. The range varies,
so the window never goes completely off‑screen (5‑digit response).
Horizontal Size (for Composite mode only)
Specify a value E
1*
X50@
*
X61@
HSIZ
}
Hsiz
X50@
*
X61@]
Set horizontal size to
X61@
.
Increment value
E
1*
X50@
+ HSIZ
}
Hsiz
X50@
*
X61@ ]
Increase width of the window.
Decrement value E
1*
X50@

}
Hsiz
X50@
*
X61@ ] Decrease width of the window.
View E
1*
X50@
HSIZ
} X61@ ] View current setting.
NOTE: Horizontal centering and horizontal size values are adjusted in multiples of 8. If a value is entered that is not a multiple of 8, the closest
acceptable value is applied and returned.
KEY:
X50@
= Output channel 01 = A, 02 = B
X61@
= Horizontal size 00120 to 04096 (5‑digit response).
