SMP 300 Series • Remote Communication and Control 134
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Record Resolution and Frame Rate
Set record resolution E X50)
*
X4^
VRES
}
Vres
X50)
*
X4^ ]
View record resolution E X50)
VRES
} X4^ ]
Set record frame rate E X50)
*
X4&
VFRM
}
Vfrm
X50)
*
X4& ]
View record frame rate E X50)
VFRM
} X4& ]
View record resolution
and frame rate (For
composite mode only)
33I
Example
Horz resolution x Vert resolution*Frame rate
]
1280x 720*30
]
View current recording
information (For
composite mode only)
1*I
Verbose mode 2/3
<ChA
X50@
*ChB
X50!
>*<
X4^
>*<
X4&
>*<
X54#
>*<
X4#
>
]
Inf*<ChA
X50@
*ChB
X50!
>*<
X4^
>*<
X4&
>*<
X54#
>*<
X4#
>
]
KEY:
X4#
= Video bit rate 00200 to 10000 (5‑digit response)
X4^
= Record resolution 480p, 720p, 1080p, 512x288, 1024x768, 1280x1024, Custom
X4&
= Record frame rate 1 = 30, 2 = 25, 3 = 24, 4 = 15, 5 = 12.5, 6 = 12, 7 = 10, 8 = 5
X50)
= Stream selection 1 = Archive Channel A, 2 = Archive Channel B (Dual Channel mode only), 3 = Confidence
X50!
= Input number 1 to 5
X50@
= Output channel 1 = A, 2 = B
X54#
= File size File size in mega Bytes
Advanced Configuration
Overscan Mode
Set overscan mode E X50$
*
X51)
OSCN
}
Oscn
X50$
*
X51)]
Sets input type
X50$
to overscan
mode
X51)
.
View overscan mode
E X50$
OSCN
} X51)]
View the current overscan
X51)
for input type
X50$
.
KEY:
X50$
= Input video format 1 = YUVp/HDTV (default), 2 = YUVi, 3 = Composite
X51)
= Overscan 0 = 0% (default: HDMI inputs), 1 = 2.5% (default: YUVp input), 2 = 5.0% (default: YUVi and composite inputs)
Test Pattern
Set test pattern E X56%
TEST
}
Test
X56%]
View test pattern
E
TEST
} X56%]
KEY:
X56%
= Test patterns 0 = Off (default), 1 = Color bars, 2 = Aspect ratio 1.33, 3 = Aspect ratio 1.78, 4 = Aspect ratio 1.85,
5 = Crop, 6 = Pulse, 7 = Timestamp (composite mode only), 8 = Universal OSD (composite mode only)
HDCP Settings (HDMI Inputs only)
View input HDCP status E
I
X50!
HDCP
} X51!]
Set input HDCP
authorization on
E
E1*
X50!
HDCP
}
HdcpE
X50!
*1
] Turn HDCP authorized device
on for input
X50!
Set input HDCP
authorization off
E
E0*
X50!
HDCP
}
HdcpE
X50!
*0
] Turn HDCP authorized device
off for input
X50!
(default)
View input HDCP
authorization
E
E
X50!
HDCP
} X(]
Enable HDCP
notification
E
N1HDCP
}
HdcpN1
] Enable green screen HDCP
notification (default)
Disable HDCP
notification
E
N0HDCP
}
HdcpN0
] Disable green screen HDCP
notification
View HDCP notification E
NHDCP
} X51@]
KEY:
X(
= On/off 0 = Disabled/off (default), 1 = Enabled/on
X50!
= Input number 1 to 5
X51!
= HDCP status 0 = No sink/source detected, 1 = HDCP detected, 2 = Sink/source detected but no HDCP
X51@
= HDCP notification 0 = Off (mute output to black), 1 = On (green HDCP notification‑screen, default)
