Extron electronics SMP 300 Series User Manual

SMP 300 Series • Remote Communication and Control 135
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Advanced Configuration continued
Safely Eject USB Storage
Eject USB storage E X59!
USBE
}
USBE
X59!]
KEY:
X59!
= Eject USB storage 0 = All USB storage, 2 = USBFront, 3 = USBRear, 4 = USBRCP
Horizontal Video Mirroring
Enable mirroring per
input
E
I
X!
*4ROTA
}
RotaI
X!
*4
]
Turn on mirroring for input
X!
.
Disable mirroring per
input
E
I
X!
*0ROTA
}
RotaI
X!
*0
]
Turn off mirroring for input
X!
.
View setting E
I
X!
ROTA
}
RotaI
X!] View mirroring setting.
KEY:
X!
= Inputs 1 through 4 (1 through 5 for SDI model)
Background Image (for composite mode only)
Select background
filename
E
lenameRF
}
Imr lename
]
View background
filename
E
RF
}
"lename"
]
Mute background
E
0RF
}
Imr0
]
Audio
Audio Input Format
Set audio format
E
I
X!
*
X3)
AFMT
}
AfmtI
X!
*
X3) ]
View E
I
X!
AFMT
} X3) ]
KEY:
X!
= Audio input 1 to 4, 1 to 5 for SDI models
X3)
= Audio format 0 = Disable audio, 1 = Analog (default for input 3), 2 = LPCM 2 CH (default)
Audio Output (Channel Selection)
Recall preset X56&
. Rpr
X56& ]
Recall audio output preset
X56&
.
KEY:
X56&
= Audio output 1 = Ch A, 2 = Ch B, 3 = Ch A + Ch B, 4 = Ch A + Ch B (Analog dual mono enabled only),
5 = Ch B Dual mono (Analog dual mono enabled only)
Audio Delay
NOTE: Set the audio delay to zero to disable it.
Set audio delay E
1*
X56$
ADLY
}
Adly1*
X56$ ]
View
E
1 ADLY
} X56$ ]
View audio delay value.
KEY:
X56$
= Audio delay 000 to 999 ms (default 0 ms, 3‑digit response)
