Extron electronics SMP 300 Series User Manual

SMP 300 Series • Remote Communication and Control 136
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Audio continued
Audio Mute
Mute audio channel E
M
X50^
*1AU
}
DsM
X50^
*1
]
Mute audio channel
X50^
.
Unmute audio channel E
M
X50^
*0AU
}
DsM
X50^
*0
]
Unmute audio channel
X50^
.
View audio channel
mute status
E
M
X50^
AU
} X(]
NOTE: The audio output mute setting applies to the stream, recording, and confidence.
KEY:
X(
= Mute/unmute 0 = Unmuted (default), 1 = Muted
X50^
= Audio selection 40000 = Analog Input A (Left), 40001 = Analog Input A (Right), 40002 = Digital input A (Left)
40003 = Digital input A (Right), 40004 = Analog Input B (Left), 40005 = Analog Input B (Right
40006 = Digital input B (Left), 40007 = Digital input B (Right), 60000 = Output (Left, for audio mute control
only), 60001 = Output (Right, for audio mute control only)
Audio Level
Set input audio level E
G
X50^
*
X50&
AU
}
DsG
X50^
*
X50&]
Set audio input channel
X50^
to
level
X50&
.
Example
E
G 40000*100AU
}
DsG40000*100
]
Set analog audio input A (left) to
+10dB.
View input audio level E
G
X50^
AU
} X50&]
View input audio channel
X50^
level
X50&
.
Example
E
G 40000AU
}
100
]
Analog audio input A (left) is set
to +10dB.
KEY:
X50^
= Audio selection 40000 = Analog Input A (Left), 40001 = Analog Input A (Right), 40002 = Digital input A (Left)
40003 = Digital input A (Right), 40004 = Analog Input B (Left), 40005 = Analog Input B (Right
40006 = Digital input B (Left), 40007 = Digital input B (Right), 60000 = Output (Left, for audio mute control
only), 60001 = Output (Right, for audio mute control only)
X50&
= Audio level Audio level in 0.1 dB steps (-180 to 240 = -18.0 to +24.0 dB)
Audio
View front panel audio
level indicators
34I
Verbose 2/3 mode
Example:
X58!
*
X58!]
Inf34*
X58!
*
X58!]
-58*-63
]
left*right
KEY:
X58!
= Front panel audio level left*right: -1500 to 0, Full bars = 0, No bars = -600
EDID Minder
Assign EDID to specific
input
E
A
X50!
*
X6*
EDID
}
EdidA
X50!
*
X6* ]
View EDID assignment E
A
X50!
EDID
} X6* ]
Import EDID to user
location
E
I
X6&
,[lename]
EDID
}
EdidI
X6&] Import a 128 or 256‑Byte binary
EDID file to the user loaded
EDID location [1 to 3].
Export EDID in binary
format
E
E
X6*
,[lename]
EDID
}
EdidE
X6* ] Export a 128 or 256‑Byte binary
EDID file from EDID location
X6*
.
[filename] can optionally carry a
full path name. The EDID file is
a .bin file, carrying 128 or 256
bytes of binary data.
KEY:
X6&
= EDID User loaded slots 1, 2, and 4
X6*
= EDID number See EDID Values on page137
X50!
= Input number 1 to 5
