SMP 300 Series • Front Panel Operations 42
EDID Resolution Refresh Rate Rate Type Video Forma Audio
1 800x600 60 Hz PC DVI N/A
2 1024x768 60 Hz PC DVI N/A
3 1280x720 60 Hz PC DVI N/A
4 1280x768 60 Hz PC DVI N/A
5 1280x800 60 Hz PC DVI N/A
6 1280x1024 60 Hz PC DVI N/A
7 1360x768 60 Hz PC DVI N/A
8 1366x768 60 Hz PC DVI N/A
9 1400x1050 60 Hz PC DVI N/A
10 1440x900 60 Hz PC DVI N/A
11 1600x900 60 Hz PC DVI N/A
12 1600x1200 60 Hz PC DVI N/A
13 1680x1050 60 Hz PC DVI N/A
14 1920x1080 60 Hz PC DVI N/A
15 1920x1200 60 Hz PC DVI N/A
16 800x600 60 Hz PC HDMI 2‑Ch
17 1024x768 60 Hz PC HDMI 2‑Ch
18 1280x768 60 Hz PC HDMI 2‑Ch
19 1280x800 60 Hz PC HDMI 2‑Ch
20 1280x1024 60 Hz PC HDMI 2‑Ch
21 1360x768 60 Hz PC HDMI 2‑Ch
22 1366x768 60 Hz PC HDMI 2‑Ch
23 1400x1050 60 Hz PC HDMI 2‑Ch
24 1440x900 60 Hz PC HDMI 2‑Ch
25 1600x900 60 Hz PC HDMI 2‑Ch
26 1600x1200 60 Hz PC HDMI 2‑Ch
27 1680x1050 60 Hz PC HDMI 2‑Ch
28 1920x1200 60 Hz PC HDMI 2‑Ch
29 480p 60 Hz HDTV HDMI 2‑Ch
30 576p 50 Hz HDTV HDMI 2‑Ch
31 720p 50 Hz HDTV HDMI 2‑Ch
32 720p 60 Hz HDTV HDMI 2‑Ch
33 1080i 50 Hz HDTV HDMI 2‑Ch
34 1080i 60 Hz HDTV HDMI 2‑Ch
35 1080p 25 Hz HDTV HDMI 2‑Ch
36 1080p 50 Hz HDTV HDMI 2‑Ch
37 1080p 24 Hz HDTV HDMI 2‑Ch
38 1080p 60 Hz HDTV HDMI 2‑Ch
39 User Loaded Slot 1
40 User Loaded Slot 2
41 User Loaded Slot 3
EDID table
