RESTRICTED USE ONLY Fargo Electronics, Inc.
Persona C30 Card Printer User Guide (Rev. 2.2)
5-83
Selecting the Defined Area(s) function (continued)
Step Procedure
4 a. Once the area is sized properly measure from the lower left corner of the
card up and over to the lower left corner for the defined area to begin.
b. Enter these values into the X and Y boxes.
(Note: The card grid lines are spaced at .2 inch / 5mm intervals.)
5 a. Print the card design and note how the image is oriented on the card as it
ejects from the Printer. (Note: The location of a defined area is based on
the card orientation as it exits the Printer.)
b. Measure the defined area location based on the printed card. (Note: If
selecting the Rotate Front 180 Degrees option, the image will appear
upside-down as it exits the Printer. In this case, position the defined area
opposite to the measurement from the onscreen card design, which will
appear right side up.)
