FCI ST100A Series User Manual

ST100A Series Flow Meter TROUBLESHOOTING
Fluid Components International LLC 103
Table 34 – Detailed CORE Fault Register (CORE 2V Command)
Octet-Bit
Status Description
Fault Type
Hex Bit Map
0-0
Device Error: If any of these errors occurs: I2C error, UART error, Mutex error, watchdog reset
Fatal
0x000000000001
0-1
FCI Reserved (Not Used)
Non-Fatal
0x000000000002
0-2
FCI Reserved (Not Used)
Non-Fatal
0x000000000004
0-3
CORE unable to update process data (PD_NO_FE_DATA). Unable to obtain/use data from any Active FEs
Fatal
0x000000000008
0-4
FCI Reserved (Not Used)
Non-Fatal
0x000000000010
0-5
CORE detects FRAM/SPI error
Fatal
0x000000000020
0-6
CORE reports SD card error. Either initialization (corrupt card) error, or card became full (error while writing). For ST100A only.
Non-Fatal
0x000000000040
0-7
FCI Reserved (Not Used)
Non-Fatal
0x000000000080
1-0
FCI Reserved (Not Used)
Non-Fatal
0x000000000100
1-1
FCI Reserved (Not Used)
Non-Fatal
0x000000000200
1-2
FCI Reserved (Not Used)
Non-Fatal
0x000000000400
1-3
FCI Reserved (Not Used)
Non-Fatal
0x000000000800
1-4
FCI Reserved (Not Used)
Non-Fatal
0x000000001000
1-5
CORE unable to communicate with one or more FEs (PD_COMM_ERROR)
Fatal
0x000000002000
1-6
FCI Reserved (Not Used)
Non-Fatal
0x000000004000
1-7
CORE: averaged flow out of range of “Flow Min” or “Flow Max”
Non-Fatal
0x000000008000
2-0
FCI Reserved (Not Used)
Non-Fatal
0x000000010000
2-1
FCI Reserved (Not Used)
Non-Fatal
0x000000020000
2-2
FCI Reserved (Not Used)
Non-Fatal
0x000000040000
2-3
CORE: averaged temperature above “Temperature Max”
Fatal
0x000000080000
2-4
CORE: averaged temperature below “Temperature Min”
Fatal
0x000000100000
2-5
FE Heater is shorted or below operating limit.
Fatal
0x000000200000
2-6
FE Heater monitoring ADC fails to respond.
Fatal
0x000000400000
2-7
FE Heater is open or above operating limit.
Fatal
0x000000800000
3-0
The Reference-R ADC converter fails to respond.
Fatal
0x000001000000
3-1
FCI Reserved (Not Used)
Non-Fatal
0x000002000000
3-2
The Reference-R ADC’s count number is below the minimum.
Non-Fatal
0x000004000000
3-3
FCI Reserved (Not Used)
Non-Fatal
0x000008000000
3-4
Process flow is above the maximum limit.
Non-Fatal
0x000010000000
3-5
FCI Reserved (Not Used)
Non-Fatal
0x000020000000
3-6
FCI Reserved (Not Used)
Non-Fatal
0x000040000000
3-7
The ADC for monitoring the temperature inside the unit fails to respond.
Non-Fatal
0x000080000000
4-0
The Delta-R ADC fails to respond.
Fatal
0x000100000000
4-1
ST80: Not used. ST100A: 4-20mA Input / Pressure Input ADC fails to respond.
Non-Fatal
0x000200000000
4-2
Reference-R value is above operating limit.
Non-Fatal
0x000400000000
4-3
The Inter-Integrated Circuit channel 0 bus fails to communicate.
Non-Fatal
0x000800000000
4-4
The ADC for monitoring heater’s conditions fails to respond.
Fatal
0x00100000000
4-5
The port expansion integrated chip fails to respond.
Non-Fatal
0x00200000000
4-6
FCI Reserved (Not Used)
Non-Fatal
0x00400000000
4-7
FCI Reserved (Not Used)
Non-Fatal
0x00800000000
5-0
The FRAM of the Flow Element fails to respond.
Non-Fatal
0x01000000000
5-1
The Active excitation current Integrated Circuit (IC) fails.
Non-Fatal
0x02000000000
5-2
The Reference excitation current Integrated Circuit (IC) fails.
Non-Fatal
0x04000000000
5-3
CORE: process data are not updated because (all) FE's are in self-test mode, or the system is in non-operating mode.
Non-Fatal
0x08000000000
5-4
Reference-R value is below operating limit.
Non-Fatal
0x10000000000
5-5
Delta-R value is above operating limit.
Non-Fatal
0x20000000000
5-6
Delta-R value is below operating limit.
Non-Fatal
0x40000000000
5-7
The unit is performing a (diagnostic) test.
Non-Fatal
0x80000000000
Notes: 1. Fault Type reflects factory default programming. The Fatal/Non-Fatal designation is programmable via the Configurator software’s FE Faults tab (Factory
branch menu tree – requires entry of appropriate level password).
