APPENDIX D – APPROVAL INFORMATION ST100A Series Flow Meter
152 Fluid Components International LLC
Safety Instructions
Safety Instructions for the use of the ST100A Series flow meter in Hazardous Areas
Certificate No. FM20ATEX0022X / IECEx FMG20.0025X
II 2 G Ex db IIC T6...T4 Gb
II 2 D Ex tb IIIC T85°C...T135°C Db
IP66/67
Instrucciones de seguridad
The ST100A Series consist of a sensing element and associated integral or remote mounted electronics
mounted in a type “d” flameproof enclosure.
The relationship between the temperature class, the maximum surface temperature, the ambient
temperature and the process temperature is as follows:
Electronic Enclosure: T6/T85°C for an ambient temperature range of
Electronic Enclosure: T5/T100°C for an ambient temperature range of
Electronic Enclosure: T4/T135°C for an ambient temperature range of
For
ATEX/IECEx Agency Approval system with AST configuration, the relationship between the
temperature class and process temperature range is as follows:
Probe: T4/T135°C for a process temperature range of -40°C to +89°C
Probe: T3/T200°C for a process temperature range of -40°C to +154°C
Probe: T2/T300°C for a process temperature range of -40°C to +254°C
Probe: T1/T450°C for a process temperature range of -40°C to +404°C
For
ATEX/IECEx Agency Approval system with Constant Power configuration, the relationship between the
temperature class and process temperature range is as follows:
Probe: T4/T135°C for a process temperature range of -40°C to +57°C
Probe: T3/T200°C for a process temperature range of -40°C to +122°C
Probe: T2/T300°C for a process temperature range of -40°C to +222°C
Probe: T1/T450°C for a process temperature range of -40°C to +372°C
Elec
trical data: Power supply: 100 – 265 VAC, 50/60 Hz, 13.1 watts max.; 24 VDC, 13.2 watts max.
