FCI ST100A Series User Manual

TROUBLESHOOTING ST100A Series Flow Meter
104 Fluid Components International LLC
Table 35 – FE Fault Register (FE DF Command)
Octet-Bit
Fault Name
Fault Description
Fault Type
1
Hex Bit Map
0-0
FCI Reserved (Not Used)
0x00000001
0-1
FCI Reserved (Not Used)
0x00000002
0-2
HTR_CURR_ADC_OVER_RANGE_FAULT
The heater current analog-to-digital converter shows
saturation at its input.
0x00000004
0-3
FCI Reserved (Not Used)
0x00000008
0-4
FCI Reserved (Not Used)
0x00000010
0-5
FCI Reserved (Not Used)
0x00000020
0-6
SENSOR_ABOVE_MAX_FLOW_FAULT
Process flow is above the maximum limit.
0x00000040
0-7
SENSOR_OVER_TEMP_FAULT
Process temperature is above the maximum limit.
0x00000080
1-0
SENSOR_UNDER_TEMP_FAULT
Process temperature is below the minimum limit.
0x00000100
1-1 HEATER_SHORTED_FAULT
The heater is shorted or its value is below the normal
operating value.
0x00000200
1-2 HEATER_OPEN_FAULT
The heater is open or its value is above the normal
operating value.
0x00000400
1-3 HTR_CURR_ADC_FAULT
The heater current analog-to-digital converter (ADC) fails
to respond.
0x00000800
1-4
dR_ADC_FAULT
The Delta-R ADC fails to respond.
0x00001000
1-5
REF_ADC_FAULT
The Reference-R ADC converter fails to respond.
0x00002000
1-6 BRD_TEMP_LIMITS_FAULT
Temperature inside the unit is outside the limits (above or
below the operating limits).
0x00004000
1-7 I2C0_FAULT
The Inter-Integrated Circuit (I2C) channel 0 bus fails to
communicate.
0x00008000
2-0 SENSOR_BELOW_MIN_ADC_FAULT
The Reference-R ADC’s count number is below the
minimum.
0x00010000
2-2
FCI Reserved (Not Used)
0x00020000
2-2
PORT_EXPANDER_FAULT
The port expansion integrated chip fails to respond.
0x00040000
2-3
BELOW_dR_MIN_FAULT
Delta-R value is below minimum limit.
0x00080000
2-4 TMP100_ADC_FAULT
The ADC for monitoring the temperature inside the unit
fails to respond.
0x00100000
2-5
LTC2654_DAC_FAULT
The digital-to-analog converter fails to respond.
0x00200000
2-6
FE_FRAM_FAULT
The FRAM of the Flow Element fails to respond.
0x00400000
2-7
FCI Reserved (Not Used)
0x00800000
3-0 HTRS_MON_ADC_FAULT
The ADC for monitoring heater’s conditions fails to
respond.
0x01000000
3-1
ACT_EXC_CURR_FAULT
The Active excitation current Integrated Circuit (IC) fails.
0x02000000
3-2 REF_EXC_CURR_FAULT
The Reference excitation current Integrated Circuit (IC)
fails.
0x04000000
3-3
SENSOR_REFR_ABOVE_ABS_MAX
Reference-R value is above operating limit.
0x08000000
3-4
SENSOR_REFR_BELOW_ABS_MIN
Reference-R value is below operating limit.
0x10000000
3-5
SENSOR_DR_ABOVE_ABS_MAX
Delta-R value is above operating limit.
0x20000000
3-6
SENSOR_DR_BELOW_ABS_MIN
Delta-R value is below operating limit.
0x40000000
3-7
FE_AUTO_CHECK
The unit is performing a (diagnostic) test.
0x80000000
Notes: 1. Fault Type reflects factory default programming. The Fatal/Non-Fatal designation is programmable via the Configurator
software’s FE Faults tab (Factory branch menu tree – requires entry of appropriate level password).
