ST100A Series Flow Meter INSTALLATION

Fluid Components International LLC 23

Electronics Enclosure Label

Affixed to the inside of the blind lid is a label that identifies the ST100A Series’ jacks and connectors (with terminal assignment). See

Figure 17 below. Use this label as a guide when wiring the instrument. Note that the PCB silkscreen also provides connector identification.

Figure 17 – ST100A Series Electronics Enclosure Label
