INSTALLATION ST100A Series Flow Meter
20 Fluid Components International LLC
Figure 14 – Remote Installation, Optional Stainless Steel Bracket on 2" Pipe
C01247-2-1
2x M4 SCREWS
(FCI PROVIDED)
2x ¼"-20
U BOL
TS, SST
4x ¼" HEX NUT
2" PIPE
ST100A SERIES
TRANSMITTER
(4.25)
(9.25)
