FCI ST100A Series User Manual

ST100A Series Flow Meter APPENDIX B – ADDITIONAL INFORMATION
Fluid Components International LLC 145
HMI Menu Outline
● Boot Screen
● Process Data Screen
□ Percentage of Flow
□
Flowrate
□
Totalizer
□
Temperature
□
Pressure
□
Group
□ Group
Name
● Service
○ Select Group
■ Password
◘ 1: [group name]
◘ 2: [group name]
◘ 3: [group name]
◘ 4: [group name]
◘ 5: [group name]
○ Alarm
Ack
■ [alarm ACK list]
○ Diagnostics
■ Show Faults
◘ [fault codes list]
■ Self Test
◘ FE 1 IDR
– Password
◘ FE2 IDR
– Password
■ Raw Signal
◘ FE1
F1 Raw Signal
– RefR: [value]
– dR: [value]
– TCdR: [value]
– Temp: [value]
– Flow: [value]
◘ FE2
F2 Raw Signal
[If present, same as above]
○ Set-up
■ Instrument
◘ Group ‘X’ [current active group]
– Flow: [eng units]
– Temp: [Deg F or Deg C]
– Pres: [press. units]
– Name: [group name]
– Restore
– Pipe: [Round or Rect.]
– W: [dimension, inch]
– H: [dimension, inch]
■ Display
◘ Orientation
[select display orientation]
◘ Contrast
[select display contrast]
■ Language
◘ English
○ LoggerSDcard
■ Remove
■ Inserted
○ Device
■ Serial No: [ser. no]
■ Sales Ord No: [sales ord. no.]
■ Core: [version no.]
■ HMI: [version no.]
■ FE1: [version no.]
■ FE2: [version no.]
○ FE Control
■ FE1: [Online or Offline]
◘ Password
FE1 Control
– Online
– Offline
■ FE2: [Online or Offline]
◘ Password
FE2 Control
– Online
– Offline
