Festo CPX-CMAX-C1-1 User Manual

4. Faults and diagnostics
4−50
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Diagnostic data of the module (I/O diagnostic
interface)
The specific representation of module diagnostic data (error
messages) of the CMAX occurs as shown in Tab.4/21 and
Tab.4/22.
Module diagnostic data: Type of error and location where error arose
Function no. 2008 + m * 4 + 0; m = module number (0 ... 47)
Description Describes where the relevant error occurred.
Bit Bit 0 ... 7 Type of error and location where error arose
Values Bit 765 ... 0 : Description
1 0 000000 : Error in I−channel 0 (axis 1)
Tab.4/21: Type of error and location where error arose
Module diagnostic data: Module error number
Function no. 2008 + m * 4 + 1; m = module number (0 ... 47)
Description Error number
Bit Bit 0 ... 7: error number
Values 100 ... 108: CPX error number, (see example Tab.4/20)
Note For CMAX error messages, see section 4.2.2.
Tab.4/22: Module error number
