The DAX IQ channels have similar status states as the DAX Audio channels. A complete accounting
of each state and the possible resolutions are detailed in the table below:
Channel
Indicator
Status Message
Issue / Corrective Action
Disabled
The DAX IQ channel has not yet been enabled. To enable, press
the DAX IQ channel button
No Panadapter
A Panadapter has not been assigned to the DAX IQ channel in
SmartSDR. Pick a Slice in SmartSDR to stream audio to the
channel by selecting the DAX channel in the Panadapter DAX IQ
settings.
No Data
The setup in SmartSDR and the DAX Control Panel are correct,
but no data is being received from the radio. This could be a
firewall issue in Windows or a setup issue in Windows. Check
these items and if all else fails, try restarting SmartSDR and/or
the radio
Busy
Only one computer at a time can be receiving DAX IQ data. The
Busy indicator shows that another computer is receiving this
DAX IQ channel. To correct, disable the DAX IQ channel on the
other computer and the busy condition on this computer will
automatically resolve
or
Not Connected
The DAX Control Panel is unable to connect to the radio. Ensure
the radio is turned on and the LED on the front of the radio is
solid green or blue. Check firewall settings in Windows to
ensure DAX can communicate with the radio. Ensure the radio
and computer are on the same TCP/IP subnet. Ensure that the
Windows firewall or any third-party firewall is not blocking
access.
Driver Error
DAX is unable to connect to the DAX RESERVED audio channels
in Windows. Open the sound settings control in Windows and
ensure that no audio devices are connected to these channels.
The DAX Control Panel must be restarted after a driver error.
Streaming
DAX is connected to the radio and streaming data to an audio
sound card in Windows. There are no setup errors.
31.2 ENABLING THE SMARTSDR CAT INTERFACE
SmartSDR CAT is a FLEX-6000 client application that translates serial port CAT commands into FLEX-
6000 “FlexLib” commands and is included with SmartSDR for Windows. It must be configured before
setting up your digital mode configuration. Please refer to the SmartSDR CAT Software User’s Guide
for detained instructions for installing SmartSDR CAT.
After SmartSDR CAT is installed, note the virtual serial port number assigned to your FLEX-6000. The
default FlexRadio virtual serial port is COM4 and will be used in this setup procedure.
