FLEX-6000 Signature Series - SmartSDR for Windows Software User’s Guide
Page 53
Copyright 2018 FlexRadio Systems. All Rights Reserved.
• CW Speed – When enabled, the knob will set the CW Speed in WPM.
• CWX Macros [1 -12] – When selected, pressing the button will send the selected CWX Macro
• None – no option is assigned to the button
15.2 OPERATING THE FLEXCONTROL
Once you have assigned a control function to a button or the knob, pressing the appropriate AUX
button will assign that function to the knob control. As an example, using the image above, AUX1 is
assigned to RIT. Pressing AUX1, will cause the LED under AUX1 to illuminate and when you rotate
the knob, it will change the RIT offset. Pressing down on the knob will reassign the knob back to
tuning the active slice.
XIT/RIT Control Functions:
In addition to changing the XIT/RIT offsets using the knob control when the respective assigned AUX
button is pressed once, if you double click the AUX button assigned to RIT or XIT the offset will reset
to 0 Hz.
15.3 TROUBLESHOOTING ISSUES WITH THE FLEXCONTROL
If the Windows system running SmartSDR cannot detect a FlexControl connected to it, the following
screen is displayed:
If you have your FlexControl physically connected to your PC and you receive the FlexControl not
detected message, the problem may be caused by one of the following:
1.) The FlexControl Drivers did not load properly – The FlexControl drivers are installed when
SmartSDR for Windows is installed. Under certain rare circumstances, Windows permissions
issues may prevent the driver from installing properly. Uninstalling and reinstalling SmartSDR
