Fujitsu Primergy RX300 S3 User Manual

118
Chapter 4 Manual OS Installation
5 Install the Drivers for onboard array controller manually.
1. When the following message appears, press the [S] key.
2. When the "Please insert the disk labeled Manufacturer-supplied hardware support
disk into Drive A:" message appears, insert the driver disk created from the driver’s
CD and press the [Enter] key.
The following message appears.
3. Select following item and press the [Enter] key.
4. When the following message appears, press the [S] key.
5. Follow the instructions in the window to perform installation
The message which prompts you to set the floppy disk appears during the installation, set
the driver disk and push the [Enter] key.
6 Follow the instructions from the setup program to continue the installation
procedure.
If a message indicating that the driver has not passed Windows Logo testing to verify its
compatibility with Windows appears, select [Yes] to continue the installation procedure.
7 Install the LAN driver.
Install the LAN driver using the driver disk created from the ServerStart CD-ROM. For more
details, refer to "4.3 Installing the LAN Driver" (
pg.126).
8 Install the LAN driver advanced set up tool.
For information about onboard LAN driver advanced setup tool, refer to "5.6.1 BACS
Installation" (
pg.160). For information about LAN card advanced setup tool, refer to "5.7.1
Intel® PROSet Installation" (
pg.169).
9 Install the ChipSet driver.
1. Insert the ServerStart Disc 1 CD-ROM into the drive of the server.
When the ServerStart window appears, exit ServerStart.
2. Execute the following command on the CD-ROM.
[CD-ROM drive] :\DRIVERS\ChipSet\Intel\5000P\infinst_autol.exe
The installation wizard starts up.
To specify additional SCSI adapters, CD-ROM drives, or special disk
controllers for use with Windows, including those for which you
have a devicesupport disk from a mass storage device manufacturer,
press S.
You have chosen to configure a SCSI Adapter for use with Windows,
using a device support disk provided by an adapter manufacturer.
Select the SCSI Adapter you want from the following list, or press
ESC to return to the
previous screen.
LSI Logic MegaRAID SAS RAID Controller Driver (Server 2003 for x64)
The driver you provided seems to be newer than the Windows default
driver.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
