PRIMERGY RX300 S3 User's Guide
7
Installing Internal Options
■ PCI Hot Plug (PHP)
• PCI slot 3 and PCI slot 4 in this server support the PHP function. If an expansion card is defective,
you can replace the defective expansion card without turning off the server and peripheral devices.
This function is available only when the OS is Windows Server 2003 x64. Using this function with
another OS may cause a failure such as system down.
• Because not all applications support the PHP function, check the support status of the applications to
use in advance.
In this server, replaceable expansion cards with the PHP function are described below. Expansion
cards other than those below are not supported.
• LAN card (PG-1892L)
• LAN Card (PG-1882L)
7.5.2 Installable Expansion Cards and Notes
This section explains expansion cards that can be installed in this server and notes on the installation.
■ Installable Expansion Cards
●
When Using a Standard Card Slot
• When replacing expansion cards using the PHP function, mare sure to call
repair service.
table: Installable Expansion Cards with Standard Installation
Installed card Model Remarks
Parallel port option PG-PP05 -
Serial port option PG-COM03
SCSI card PG-1301L Ultra160 SCSI
Fiber channel card PG-FC202 PCI Express
LAN card PG-2861L PCI Express
LAN card (1000BASE-T) PG-1892L -
LAN card (1000BASE-SX) PG-1882L 1000BASE-SX

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
