Fujitsu Primergy RX300 S3 User Manual

204
Chapter 7 Installing Internal Options
7.6 Installing Internal Hard Disk
Units
This section explains how to install internal hard disk units.
• Before installing an internal hard disk unit, turn off the server and all peripheral
devices, and unplug all power cables from the server. Failure to do so may
cause electric shock ("1.4.3 Turning Off the Server" (pg.33)).
When an array system is configured (RAID 1/5), optional 3.5-inch internal
devices can be replaced without shutting down the server.
• Rough handling of hard disk units can damage the stored data. To cope with
any unexpected problems, always back up important data. When backing up
data to another hard disk unit, we recommend that you make backups on a file
or block basis.
• Use the unit in a dry place with low dust levels.
• Be careful not to hit the hard disk unit or bring it into contact with metallic
objects.
• The circuit boards and soldered parts of internal options are exposed and can
be damaged by static electricity.
Before handling them, first touch a metal part of the server to discharge static
electricity.
• Do not touch the circuitry on boards or soldered parts. Hold the metallic areas
or the edges of the circuit boards.
• Use the device on a shock and vibration free surface.
• Keep the device away from direct sunlight and from radiators or other heat
sources.
• Do not use the unit in extremely hot or cold locations, or locations with extreme
temperature changes.
• Never attempt to disassemble the hard disk unit.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
