Fujitsu Primergy RX300 S3 User Manual

242
Chapter 8 Configuring Hardware and Utilities
8.1.9 The Power On/Off Submenu
This submenu appears when you select [Power On/Off] from the Advanced menu.
Use this submenu to configure the power on/off settings.
table: Items on the Power On/Off Submenu
Item Setting Description
Power-Off Source -
Software Enabled (Unchangeable) Sets whether to turn the power off by the program
or by the OS.
Power Button Enabled (Unchangeable) Sets whether or not to allow the use of the power
switch for turning the power off, when the ACPI
function is disabled.
Power-On Source BIOS Controlled
(Unchangeable)
Sets to turn the power on.
Remote Enabled (Unchangeable) Sets whether or not the power is turned on when the
modem (connected to the serial port) receives a ring
signal.
LAN Enabled (Unchangeable) Sets whether or not to enable the power to be turned
on via LAN.
Wake Up Timer Disabled (Unchangeable) Sets whether or not the power is turned on at a
certain time or after a certain time has passed.
Wake Up Time Sets when to turn the power on by timer.
Wake Up Mode Sets the interval to turn the power on by timer.
Power Failure Recovery • Always On
•Always Off
• Previous State (Initial
value)
Sets the state of the power when the system goes
down due to abnormal power, or after turning the
power back on by UPS.
Note:
 When UPS is used, be sure to set to
"Always ON".
PhoenixBIOS Setup Utility
Item Specific Help
Select Item
Select Menu
Change Values
Select > Sub-Menu
-/+
Enter
F1
Esc
Help
Exit
F9
F10
Setup Defaults
Save and Exit
Advanced Security Server ExitMain
Advanced System Configuration
Power Off Source
Software:
Power Button:
Power On Source
Remote:
LAN:
Wake up Timer:
Wake up Time:
Wake up Mode:
Power Failure Recovery:
[Enabled]
[Enabled]
[Bios Controlled]
[Enabled]
[Enabled]
[Disabled]
[00:00:00]
[Daily]
[Previous State]

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
