Fujitsu Primergy RX300 S3 User Manual

170
Chapter 5 Operations after OS Installation
5.7.2 Cautions for PG-185x/186x/188x/189x/286x LAN
Driver V10.1
■ Event Log
Once a Team is setup, multiple identical logs from the same source that starts with the following log may
be stored in the system log file of the event viewer at system start-up.
Since such event logs will be stored even if the Teaming function is operated normally, ignore them.
5.7.3 Teaming Function
■ Notes
When using the Teaming function, note the following points.
• You require Service Pack 2 or later for Windows 2000 Server.
• For AFT/ALB/Static link type, you can incorporate up to four LAN ports into one team and two ports
for a SFT type team.
• Once a Team is created, virtual adapters (Team:(Team Name)) will be created in the [Device
Manager] and/or [Network and Dial-up Connections] of the system. Do not disable or delete this
virtual adapter from the [Device Manager] or [Network and Dial-up Connections]. When deleting a
virtual adapter, make sure to use "Intel
®
PROSet".
• When the Teaming function is being used, you can only use the following protocols:
• For AFT/SFT/Static link type: IP, NetBEUI, IPX (NCP), IPX (NetBIOS)
• For ALB type: IP, IPX (NCP)
• When the Teaming function is being used, you cannot use the hardware assist function of IPSEC. Do
not use this function even if the function is installed in all cards in the team.
• When the Teaming function is being used, you cannot use Windows Load Balancing Service
(WLBS) and Network Load Balancing (NLB).
• If Static link type is selected, you can only use the switch for link aggregation.
• When adding/deleting a Static link type member, perform such operation under a linked down state.
• When using the onboard LAN to control remotely with RemoteControlService, it cannot be a
member of the Team. For details on RemoteControlService, refer to "ServerView User's Guide".
• If the onboard LAN is set to RemoteControlService and Team is configured on the onboard LAN,
remote control function with RemoteControlService does not work properly.
• The team with the Intel
®
PROSet Broadcom onboard LAN and the Intel LAN card can be
configured, but note the following points.
Source iANSMiniport
ID 11
Type Warning
Description The following adapter link is not connected: (adapter name)
* (adapter name) varies depending on the OS or hardware configuration.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
