257
PRIMERGY RX300 S3 User’s Guide
9
Operation and Maintenance
9.2 Troubleshooting
This section explains the resolutions when the server is not running properly or when
error messages are displayed.
For each situation, refer to the following.
Hardware problems.
"9.2.1 Hardware Troubleshooting" (pg.257)
Error messages.
"9.2.2 Error Messages" (pg.260)
Software problems.
"9.2.3 Software Troubleshooting" (pg.266)
If the problem is not resolved after performing the following troubleshooting, contact an office listed in
the "Contact Information" of the "Start Guide".
When contacting an office listed in the "Contact Information" of the "Start Guide", refer to "9.8.1
Contacting Maintenance Support" (
pg.288) and collect the required information.
Information for PRIMERGY
For the latest information on PRIMERGY, update modules, drivers and the software, refer to the Fujitsu
PRIMERGY website (http://primergy.fujitsu.com).
9.2.1 Hardware Troubleshooting
This section explains hardware related troubleshooting. If the server does not operate properly or if a
failure is suspected, check the following.
For optional devices, refer to the manual included with the optional device.
Server
The server does not power on, or the power LED on the front of the server
does not light up.
Check to see whether the power cable is properly connected to the outlet.
For instructions on connecting the power cable, refer to "Start Guide".
An error message is displayed.
Refer to "9.2.2 Error Messages" (pg.260).
When an expansion card is added, other expansion cards or onboard
devices are not recognized.
Reinstall the drivers for the expansion cards or onboard devices that are not recognized.

Table of Contents

Other manuals for Fujitsu Primergy RX300 S3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu Primergy RX300 S3 and is the answer not in the manual?

Fujitsu Primergy RX300 S3 Specifications

General IconGeneral
Tcase78 °C
Bus typeFSB
FSB ParityYes
Processor cache4 MB
Processor cores2
Processor model5080
Processor seriesIntel Xeon 5000 Series
Processor socketLGA 771 (Socket J)
Processor threads4
Processor codenameDempsey
Motherboard chipsetIntel® 5000P
Processing Die size162 mm²
Processor frequency3.73 GHz
Processor cache typeL2
Processor lithography65 nm
Processor system typeDP
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor front side bus1066 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)130 W
Processor core voltage (AC)1.25 - 1.40 V
CPU multiplier (bus/core ratio)14
Number of Processing Die Transistors376 M
Maximum graphics card memory8 MB
Memory slots8
Internal memory2 GB
Internal memory typeDDR2-SDRAM
Maximum internal memory32 GB
Memory layout (slots x size)2 x 1 GB
Networking featuresEthernet/Fast Ethernet/Gigabit Ethernet
Expansion slots1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level56 dB
Chassis typeRack (2U)
Compatible operating systemsWindows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports8 x SAS
Power supply600 W
Power requirements100 - 240V, 50/60 Hz
Operating temperature (T-T)10 - 35 °C
SafetyIEC 60950-1, EN 60950-1
Electromagnetic compatibilityEN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels1, 5, 10, 50
Processor ARK ID27213
Weight and Dimensions IconWeight and Dimensions
Depth785 mm
Width483 mm
Height86 mm
Weight25000 g
