PRIMERGY RX300 S3 User's Guide
8
Configuring Hardware and Utilities
8.1.5 The Advanced Menu
The Advanced menu sets the peripheral device and PCI device options.
table: Items on the Advanced Menu
Item Setting Description
Peripheral Configuration Configures the serial port, parallel port, etc.
"8.1.6 The Peripheral Configuration Submenu" (pg.236)
PCI Configuration Configures the PCI device.
"8.1.7 The PCI Configuration Submenu" (pg.238)
Advanced System
Configuration
Configures additional settings.
"8.1.8 The Advanced System Configuration Submenu" (pg.240)
Power On/Off Configures the power on/off settings.
"8.1.9 The Power On/Off Submenu" (pg.242)
IPMI Configures the integrated Remote Management Controller (iRMC) settings.
"8.1.10 The IPMI Submenu" (pg.243)
Reset Configuration Data • Yes
• No (Initial value)
Configures the initialization of the Extended
System Configuration Data (ESCD) that retains
system resources.
Multiprocessor
Specification
1.4 (Unchangeable) Sets the version of the used multiprocessor table.
The multiprocessor table is required when a
multiprocessor OS detects the multiprocessor
characteristics of the system.
Peripheral Configuration
PCI Configuration
Advanced System Configuration
Power On/Off
IPMI
Reset Configuration Data:
Multiprocessor Specification:
[No]
[1.4]
>
>
>
>
>
PhoenixBIOS Setup Utility
Item Specific Help
Select Item
Select Menu
Change Values
Select > Sub-Menu
-/+
Enter
F1
Esc
Help
Exit
F9
F10
Setup Defaults
Save and Exit
Advanced Security Server ExitMain
Setting items on this menu to incorrect values
may cause your system to malfunction.
Setup Warning

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
