Fujitsu Primergy RX300 S3 User Manual

260
Chapter 9 Operation and Maintenance
9.2.2 Error Messages
This section explains the error messages for this server.
■ POST Error Messages
When an error occurs during POST (Power On Self Test: a device check performed during the server
startup process) on this server, take the corresponding corrective actions described in the table below.
table: List of POST error messages
Message Description
Failure Fixed Disk 0 From the BIOS Setup Utility, check the [Standard IDE] setting
of "8.1.2 The Main Menu" (pg.231) and the [ATA Controller
Config] setting of the [Advanced] menu -"8.1.6 The Peripheral
Configuration Submenu" (pg.236). If the message still
appears, contact an office listed in the "Contact Information" of
the "Start Guide".
Failure Fixed Disk 1
Fixed Disk Controller Failure
Keyboard error Check to see whether the keyboard is connected properly. If the
message still appears, the keyboard must be replaced.
Keyboard controller error The keyboard is abnormal. Replace the keyboard or mouse. If
the message still appears, the baseboard must be replaced.
Contact an office listed in the "Contact Information" of the
"Start Guide".
Keyboard error nn Remove objects, if any, that are pressing against any keys on the
keyboard. ("nn" is a hexadecimal code representing the key.)
Check to see whether the keyboard is connected properly. If the
message still appears, the keyboard must be replaced.
Stuck Key nn
Keyboard locked - Unlock key switch Check to see whether the keyboard is connected properly. If the
message still appears, the keyboard must be replaced.
Monitor type does not match CMOS - Run
Setup
An invalid monitor type is set.
Contact an office listed in the "Contact Information" of the
"Start Guide".
Critical memory error occurred - system
halted
The memory is abnormal. Stop the server once, then restart it. If
the message still appears, check the error log and replace the
faulty memory.
Extended RAM Failed at offset: nnnn
System RAM Failed at offset: nnnn
Shadow RAM Failed at offset: nnnn
Memory type mixing detected The installation configuration of the memory is wrong. Verify
that the same type of memory is installed to the slots of the same
memory pair. If the memory is properly installed, it needs to be
replaced.
Memory Redundancy Feature could not
configure the Mirror DIMMs
Memory Mirroring cannot be configured. Confirm the memory
pair that configures the mirror is on the DIMMs of the same
capacity. If the memory is installed properly, it must be
replaced.
Correctable memory error in module x The memory is abnormal. Replace the memory module that
corresponds to "module n" (where n is the slot number).
Uncorrectable memory error in module x
Memory decreased in Size Power off the server and turn it back on. If the message still
appears, check the error log and replace the faulty memory.
Non Fujitsu Siemens Memory Module
detected Warranty void!
The memory is abnormal.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
