Fujitsu Primergy RX300 S3 User Manual

15
PRIMERGY RX300 S3 User’s Guide
1
Overview
■ High-speed Processing
●
Dual Core Intel

Xeon

Processors
The server can have up to two dual core Intel® Xeon® processors for high-speed data processing (one
processor in standard servers).
The server supports the 64-bit processing and the Hyper-Threading function providing high-efficiency
and high-speed processing.
● PCI-Express, PCI-X
The server uses PCI-Express buses with a maximum data transfer speed per one lane and one direction
of 2.5Gbps and PCI-X buses with a maximum data transfer speed of 1066MBps, which provide high-
speed data transferring.
■ Compact Design and Scalability
●
Space Saving 2U Design
This server is slim, with a thickness of 2U. The server, display device, keyboard, and external SCSI
options fit in a 19-inch rack, which saves the installation space.
● Maximum Memory Size of 16GB
In addition to the preinstalled 1GB memory, the system has eight memory banks for supporting up to
16GB memory.
● Maximum Hard Disk Size of 880.8GB
Up to six internal hard disk units can be installed in the 3.5-inch storage bays. The hard disk size can be
increased up to 880.8GB.
● With a Standard Internal CD-ROM Drive Unit
The server has one standard internal CD-ROM drive unit.
● Five PCI slots
The server has five Lowprofile PCI slots, including three PCI-Express slots and two PCI-X slots.
Functions can be added by using expansion cards.
By using a card slot conversion kit, three fullHeight PCI-X slots can be used.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
