PRIMERGY RX300 S3 User’s Guide
1
Overview
h Rear maintenance LED / System identification LED ( )
This LED lights amber when the server is not turned on (standby mode). When the server is
turned on and an error is detected in a server component, this LED lights or blinks amber (OFF in
normal status).
If this LED lights or blinks when the server is turned on, contact an office listed in the "Contact
Information" of the "Start Guide".
When pressing the system identification LED button located on the front of the server, the front
and rear LEDs are lit blue so that the locations of devices being maintained can be determined.
Also, the [System Identification LED Display] button of ServerView can be used to light them.
i Keyboard connector (6 pins) ( )
A keyboard is plugged in.
j Serial port 1 (9 pins) ( )
Cables of peripheral equipment conforming to the RS-232C standard such as modems are
plugged in. This port can also be used as a server management port by changing BIOS setting.
For how to use the server management port, refer to "Appendix C Using the Server Management
Port" (
pg.297).
k USB connector ( )
Connects peripheral equipment conforming to the USB standard (2.0 or 1.1).
l Display connector (15 pins) ( )
A display cable is plugged in.
m LAN connector A (10/100/1000BASE-T) ( )
An Unshielded Twisted Pair (UTP) cable is plugged in. For 1000Mbps connection, a cable
conforming to category 5 enhanced is required. The meanings of the two LED are shown in the
table below.
n LAN connector B (10/100/1000BASE-T) ( )
This is a common port for the OS and the Remote Management Controller (iRMC: integrated
Remote Management Controller). The meanings of the cables and LEDs are the same as LAN
connector A. This can be used as a LAN port for Remote Management Controller by setting from
the BIOS Setup Utility.
For details about Remote Management Controller, "Appendix D Remote Management
Controller" (
pg.302).
table: LAN connection status
LED
location
LED status Connection status
Right Lights green Link is being established
Blinks green Data is being transferred.
Off Link is not established.
Left Lights amber Connection is established at 1000Mbps.
Lights green Connection is established at 100Mbps
Off Connection is established at 10Mbps or the LAN is not
connected.
ID
LAN A/LAN B
LAN A/LAN B

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
