PRIMERGY RX300 S3 User’s Guide
9
Operation and Maintenance
■ Error Messages during Installation
The following error messages may appear during installation using ServerStart. Check the corrective
action against the relevant error.
● "WzDiskAdmin: System Error! ......................, Last Error: The device is not
ready." appears.
Optional SCSI devices (e.g., hard disk cabinet, or DAT unit) may be connected. Disconnect the optional
SCSI devices and perform installation again. Connect the optional devices after the installation
completes.
● "Operating System not found" appears when the system restarts after file
copy from the CD-ROM.
The following are possible causes. Check them.
• The array controller card comes later than the onboard SCSI array controller in order of device
startup.
• The Active flag is specified.
• The BIOS setting of the RAID card connected to the internal hard disk unit is set to [Disable]. For
details on the BIOS setting of the RAID card, refer to the user guide supplied with the RAID card.
● "Missing Operating System" appears during installation.
The installation partition size may be too large. Specify the installation partition size correctly.
For details on the installation partition size, refer to "2.3.1 Installation Partition Size" (
pg.47).
● "Error 1920. Service (PXE Services) failed to start" appears during
preconfigured installation.
The system installed with the preconfigured settings (PXE server) may not be connected to the network.
Check the LAN cable connection and click [Rerun].
■ An application where the tftp client function (tftp.exe) is used does
not operate properly
In the system in which Windows Server 2003 is installed, the tftp client function (tftp.exe) is not
installed by default, and the application where the tftp client function (tftp.exe) is used does not operate
properly.
To use the tftp client function (tftp.exe), install "tftp.exe" from the OS CD-ROM according to the
following procedures.
1 Insert the OS CD-ROM into the CD-ROM drive.
The OS CD-ROM must be either Windows Server 2003 CD that has applied SP1, Windows
Server 2003 x64 CD or Windows Server 2003 R2 Disc 1 CD.
2 Move to the i386 folder of CD-ROM drive.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
