PRIMERGY RX300 S3 User’s Guide
3
OS Installation Using ServerStart
● Remote Installation Using a Remote Resource Server
In remote installation using a remote resource server, ServerStart starts up on the target server.
Procedures for starting installation are the same as those in normal installation (preconfiguration,
guided, and expert modes). Once installation started, resources necessary for installation are provided
from the remote resource server. Thus, procedures such as inserting a CR-ROM are not necessary.
■ System Requirements for Remote Resource/PXE Servers
Because remote installation is performed via a network, the environment must have at least one
Windows server and a local area network.
In addition, the following environment is required.
■ Remote Resource/PXE Server Requirements
Notes on the PXE server
 Check that no other PXE server exists on the same LAN.
 Servers installed with software with the PXE function such as SystemcastWizard/SystemcastWizard
Professional, Quick Recovery Manager, or the Microsoft RIS function cannot be used as a PXE server.
table: System Requirements for Remote Resource/PXE Servers
PXE server Remote resource server
OS Windows 2000 Server SP2 to 4
Windows Server 2003
Windows Server 2003
Windows 2000 Server
Windows NT Server 4.0
Memory 256MB or more 256MB or more
Operating
environment
• DHCP server function (required on the same
network)
• File sharing function (required)
• File sharing function (required)
Target server
Remote resource server
A
ctive ServerStart
and start installation
1) Request resources
Supply resources2)
- OS
- Service Pack
- Application
etc.

Fujitsu Primergy RX300 S3 Specifications

General

Tcase	78 °C
Bus type	FSB
FSB Parity	Yes
Processor cache	4 MB
Processor cores	2
Processor model	5080
Processor series	Intel Xeon 5000 Series
Processor socket	LGA 771 (Socket J)
Processor threads	4
Processor codename	Dempsey
Motherboard chipset	Intel® 5000P
Processing Die size	162 mm²
Processor frequency	3.73 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.25 - 1.40 V
CPU multiplier (bus/core ratio)	14
Number of Processing Die Transistors	376 M
Maximum graphics card memory	8 MB
Memory slots	8
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 1 GB
Networking features	Ethernet/Fast Ethernet/Gigabit Ethernet
Expansion slots	1 x PCIe x8, 2 x PCIe x4, 2 x PCI-X
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	56 dB
Chassis type	Rack (2U)
Compatible operating systems	Windows Server 2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, VMware ESX
I/O ports	8 x SAS
Power supply	600 W
Power requirements	100 - 240V, 50/60 Hz
Operating temperature (T-T)	10 - 35 °C
Safety	IEC 60950-1, EN 60950-1
Electromagnetic compatibility	EN 55 022 A, EN 55024, EN 61000-3-2 / -3-3
RAID levels	1, 5, 10, 50
Processor ARK ID	27213

Weight and Dimensions

Depth	785 mm
Width	483 mm
Height	86 mm
Weight	25000 g
