FUTABA 6k - Throttle Curve

102
Airplane
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL1AIL1FLP 2AIL1FLP ELEVONWING TYPE
However, this function cannot be used when the throttle EXP function was set. When this function is set,
the throttle EXP function cannot be used.
This function sets a 5 point throttle curve so that
the engine/motor speed relative to movement of the
throttle stick is the optimum value for ight.
●A curve can be set for each switch position.
"THR CRV"
THR CRV
Throttle curve
(AIRPLANE)
■ Activating the function
＋ －
or
① Select the "MIX" item
and then select the
"ON" by pressing the +
key or – key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Select the "SW" item
and then select the
switch by pressing the
+ key or – key.
Range：SwA ～ SwD Default：SwC
■ 5 point curve set
＋ －
or
③ By Jog key, either of P-1 to P-5 is chosen. The + key or - key is pressed and a
rate is set up.
Range：0 ～ 100%
Default：P-1:0%, P-2:25%, P-3:50%, P-4:75%, P-5:100%
Throttle curve
Activating the function
Switch selection
5 point curve
set
● Select the setting item
with the Jog key.
● When not using this function,
select INH.
● The set-up curve is shown
（Present switch position）
