■ Activating the function
＋ －
or
① Select the "MIX" item
and then select the on
or o by pressing the +
key or – key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Select the "SW" item
and then select the
switch by pressing the
+ key or – key.
Range：SwA ～ SwD Default：SwC
■ Switch direction
③ Select the "POSI" by pressing the
+ key or – key at the ON direction
selection item.
Range：
● 2P SW：NULL, UP, DOWN
● 3P SW：NULL, UP, UP&DWN,
UP&CNT, CENTER, CNT&DN, DOWN
■ Idle down rate
＋ －
or
④ Select the "RATE" item and
then adjust the idle down
rate by pressing the + key or
– key.
Range：0 ～ 40%
Default：0%
● When you want to return the set value to the initial
value, press the + key and – key simultaneously.
Idle down
This function is linked to the air brake switch
and gear switch and lowers the engine idle. It is
used when engine idle is set high to prevent the
engine from stalling during ight and you want to
lower engine idle when landing.
●The amount engine idle is lowered can be set.
●At idling down operation, the stop lever adjusts the
idle down amount.
●Function operation can be selected from among
switches A
〜
D. The switch direction can also be
selected.
● The idle down amount is usually 10% 〜 20%. Hold down the aircraft and set the throttle switch to the maximum
slow position while the engine is running and adjust the idle drop amount while turning the switch on and o.
"IDL DWN"
IDL DWN
Idle down
(AIRPLANE)
Activating the function
Idle down rate
Switch selection
Switch direction
● When not using this Function
select INH. The display of On/
O is shown when active and
assigned to a switch.
● Select the setting item
with the Jog key.
● Sets the ON/OFF direction of the selected switch.
○ 2P SW：NULL, UP, DOWN
○ 3P SW：NULL, UP, UP&DWN, UP&CNT, CENTER, CNT&DN, DOWN
