S.BUS/S.BUS2 DEVICE SETTING
S.BUS/S.BUS2 servos or a telemetry sensor can be connected directly to the T6K. Channel
setting and other data can be entered for the S.BUS/S.BUS2 servos or sensors.
3-way hub
or Y-harnesses
(S.BUS/S.BUS2
Servo)
S.BUS/S.BUS2
device
(Telemetry sensor)
Receivers
Battery
Back of T6K
1. Turn on the transmitter power.
2. Call the setup screen.
Servo:
→
S.BUS
3. Connect the S.BUS device and battery you
want to set with a 3-way hub or Y-harnesses
as shown in the gure.
4. Perform setting in accordance with each
screen.
5. This sets the channel and other data for each
S.BUS servo, or telemetry device to be used
with the S.BUS device or receiver.
To Next Page
