① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
The up/down travel of each flap/aileron (
flaps: FLP5, ailerons: AIL1/6) can be adjusted
independently for each servo according to the
wing type. The camber operates by switch A.
●The axis of each ap can be shifted
●The control switch can be changed
"CAMBER"
CAMBER
Camber
(GLIDER)
● Select the setting item
with the Jog key.
● The value is changed by
+ key or – key.
●
Current switch position
●
Switch position
● Elevator
● Aileron 1
● Aileron 6
● Flap
● Activating the function
● Switch selection
＋ －
CH1
Aileron 1
Aileron 6
Flap 5
CH6
CH5
