① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
● OFF-position
(0% : OFF)
● ON-position
(100% : High)
This function sets the operating motor when
the EP glider with motor is started by switch. The
operating speed can individually set in 2 ranges
of high from slow and slow from high. If you do
motor control with a throttle stick, you should
set this function to INH.
●For safety, the ON/OFF switch of the aircraft itself
can be set.
●If a transmitter power supply is switched on while
the motor SW has been ON, the warning will
operate. Be sure to switch on a power supply with
the motor-start switch OFF.
"MOT SW"
MOT SW
Motor switch
(GLIDER)
■ Activating the function
＋ －
or
① Select the "MODE" item
and then select the
"OFF" by pressing the
+ key or – key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Change the switch by
pressing the + key or
– key at the switch
selection item.
Range：SwA ～ SwD
■ Switch direction
＋ －
or
③ Select the
"DOWN" it em
and then select
the position by
pressing the + key or – key.
● 2P SW： UP, DOWN
● 3P SW： UP, UP&D, UP&C, CNTR,
C&DN, DOWN
■ Speed setting
④ Select "SPEED " next to (OFF) and (ON) by Jog key.
Range：OFF, 1 ～ 10 (more slowly)
●
(ON)
is the acceleration speed setting.
●
(OFF)
is the deceleration speed setting.
Motor
● Start SW
● Accelerating speed setting
● Decelerating speed setting
● If this safety switch
is not ON, the
motor will not start
even if the starter
switch is turned on.
In "NULL", a safe
function does not
work.
● Present motor
control position
Always remove the propeller from the motor during setting and at operation checks.
■There is the danger of the propeller spinning unexpectedly and causing a serious injury.
