FUTABA 6k - Elevator→Camber Mixing

146
Glider
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL1AIL1FLP 2AIL1FLP 2AIL2FLPWING TYPE
● (RT1) and (RT2) show the
direction of elevator of
operation.
Elevator
(CH2)
Aileron 1
(CH1)
Aileron 6
(CH6)
Flap
(CH5)
"EL → CMB"
EL → CMB
Elevator → Camber mixing
(GLIDER)
Up the elevator
ap is down
● Select the setting item
with the Jog key.
● The value is changed by
+ key or – key.
● Current position of the
elevator stick
● Described on
the next page.
● Aileron 1
● Camber MIX ACT/INH
Mixing rate
● Aileron 6
● Can be either set to a
switch or when NULL is
always active.
● Flap 5
● Flap 3
[ELE → Camber ２page]
（Currently selected condition）
（Currently selected condition）
＋ －
This function is used when you want to mix the
camber aps with elevator operation. When used,
the flaps are lowered by up elevator, and lift is
increased.
● In-ight mixing can be turned ON/OFF by assigning
this to a switch. (Always ON at SW [NULL] setting)
● The mixing rate can be adjusted.
● Setting so that the aps are not operated near the
center of the elevators is possible. (RANGE)
● It can't be set.
＜ It's caused by the
wing type. ＞
● Sets the ON/OFF direction of
the selected switch.
