FUTABA 6k - Camber Mixing

148
Glider
Function
Method
① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
1AIL 2AIL1AIL1FLP 2AIL1FLP 2AIL2FLPWING TYPE
"CMB MIX"
CMB MIX
Camber mixing
(GLIDER)
● Select the setting item
with the Jog key.
● The value is changed by
+ key or – key.
● Amount of compensation
of the elevator when the
camber changed.
● Aileron 1
● Camber MIX ACT/INH
Sets the amount of
movement when
the VR was turned.
● Aileron 6
● Flap 5
● Flap 3
● Can be set to operate from
a switch. When NULL, it is
operated by a VR.
[CMB MIX ２page]
（Currently selected condition）
（Currently selected condition）
＋ －
All the wing control surfaces are
lowered and the camber is increased
(lift increases)
Attitude changes are compen-
sated for by setting the
amount of elevator movement.
Attitude changes are compen-
sated for by setting the
amount of elevator movement.
Turn the VR
All the wing control surfaces are
raised and the camber is
decreased (lift decreases)
This function adjusts the rate of camber
operation for the wing camber (ailerons, ap) in
the negative and positive directions. The aileron,
flap, and elevator rates can also be adjusted
independently and attitude changes caused by
camber operation can be corrected.
*Initial setting assigns camber operation to VR.
● Operation can be turned on and off by switch
● VR can be changed by AUX channel 5
(RT1)：The amount of
operations when VR is turned to
the right.
(RT2)：The amount of
operations when VR is turned to
the left.
● Sets the ON/OFF direction of
the selected switch.
